Section 19 Serial Communication Interface with FIFO (SCIF)

Rev. 4.00 Sep. 14, 2005 Page 715 of 982

REJ09B0023-0400

Bit Bit

Name

Initial
value R/W

Description

Receive FIFO Data Trigger

Set the quantity of receive data which sets the receive
data full (RDF) flag in the serial status register
(SCFSR). The RDF flag is set when the quantity of
receive data stored in the receive FIFO register
(SCFRDR) is increased more than the set trigger
number shown below.

• Asynchronous mode

• Synchronous mode

7

6

RTRG1

RTRG0

0

0

R/W

R/W

00: 1

01: 4

10: 8

11: 14

00: 1

01: 2

10: 8

11: 14

5

4

TTRG1

TTRG0

0

0

R/W

R/W

Transmit FIFO Data Trigger 1, 0

Set the quantity of remaining transmit data which sets
the transmit FIFO data register empty (TDFE) flag in the
serial status register (SCFSR). The TDFE flag is set
when the quantity of transmit data in the transmit FIFO
data register (SCFTDR) becomes less than the set
trigger number shown below.

00: 8 (8)*

01: 4 (12)*

10: 2 (14)*

11: 0 (16)*

Note: * Values in parentheses mean the number of

empty bytes in SCFTDR when the TDFE flag is
set to 1.

3

MCE

0

R/W

Modem Control Enable

Enables modem control signals

CTS and RTS.

In synchronous mode, MCE bit should always be 0.

0: Modem signal disabled*

1: Modem signal enabled

Note: *

CTS is fixed at active 0 regardless of the input
value, and

RTS is also fixed at 0.
