Section 24 List of Registers
Rev. 4.00 Sep. 14, 2005 Page 887 of 982
REJ09B0023-0400
Register
Abbreviation
Bit
31/23/15/7
Bit
30/22/14/6
Bit
29/21/13/5
Bit
28/20/12/4
Bit
27/19/11/3
Bit
26/18/10/2
Bit
25/17/9/1
Bit
24/16/8/0 Module
CMSTR_1 — — — — — — — — CMT
— — — — — — — STR
CMCSR_1 — — — — — — — —
CMF — CMR1 CMR0 — — CKS1 CKS0
CMCNT_1
CMCOR_1
TCR_3 CCLR2 CCLR1 CCLR0 CKEG1 CKEG0 TPSC2 TPSC1 TPSC0 MTU
TCR_4 CCLR2 CCLR1 CCLR0 CKEG1 CKEG0 TPSC2 TPSC1 TPSC0
TMDR_3 — — BFB BFA MD3 MD2 MD1 MD0
TMDR_4 — — BFB BFA MD3 MD2 MD1 MD0
TIORH_3 IOB3 IOB2 IOB1 IOB0 IOA3 IOA2 IOA1 IOA0
TIORL_3 IOD3 IOD2 IOD1 IOD0 IOC3 IOC2 IOC1 IOC0
TIORH_4 IOB3 IOB2 IOB1 IOB0 IOA3 IOA2 IOA1 IOA0
TIORL_4 IOD3 IOD2 IOD1 IOD0 IOC3 IOC2 IOC1 IOC0
TIER_3 TTGE TGFASEL — TCIEV TGIED TGIEC TGIEB TGIEA
TIER_4 TTGE TGFASEL — TCIEV TGIED TGIEC TGIEB TGIEA
TOER — — OE4D OE4C OE3D OE4B OE4A OE3B
TOCR — PSYE — — — — OLSN OLSP
TGCR — BDC N P FB WF VF UF
TCNT_3
TCNT_4
TCDR
TDDR
TGRA_3
