Section 10 Interrupt Controller (INTC)
Rev. 4.00 Sep. 14, 2005 Page 230 of 982
REJ09B0023-0400
Table 10.3 Correspondence between Interrupt Sources and IMR0 to IMR10
Bit Name (Function Name)
Register
Name
7 6 5 4 3 2 1 0
IMR0 IRQ7 IRQ6 IRQ5 IRQ4 IRQ3 IRQ2 IRQ1 IRQ0
(IRQ) (IRQ) (IRQ) (IRQ) (IRQ) (IRQ) (IRQ) (IRQ)
IMR1 TxI0 BRI0 RxI0 ERI0 DEI3 DEI2 DEI1 DEI0
(SCIF0) (SCIF0) (SCIF0) (SCIF0) (DMAC) (DMAC) (DMAC) (DMAC)
IMR2  — — ADI0 TxI1 BRI1 RxI1 ERI1
(ADC0) (ADC0) (ADC0) (ADC0) (SCIF1) (SCIF1) (SCIF1) (SCIF1)
IMR4 — — — — ITI — — —
— — — — WDT WDT WDT WDT
IMR5 TxI2 BRI2 RxI2 ERI2 ADI1 USIHP USI1 USI0
(SCIF2) (SCIF2) (SCIF2) (SCIF2) (ADC1) (USB) (USB) (USB)
IMR6 TCI2U TCI2V TGI2B TGI2A TCI1U TCI1V TGI1B TGI1A
(MTU2) (MTU2) (MTU2) (MTU2) (MTU1) (MTU1) (MTU1) (MTU1)
IMR7 — — — TCI0V TGI0D TGI0C TGI0B TGI0A
(MTU0) (MTU0) (MTU0) (MTU0) (MTU0) (MTU0) (MTU0) (MTU0)
IMR8 — — — TCI3V TGI3D TGI3C TGI3B TGI3A
(MTU3) (MTU3) (MTU3) (MTU3) (MTU3) (MTU3) (MTU3) (MTU3)
IMR9 — — — TCI4V TGI4D TGI4C TGI4B TGI4A
(MTU4) (MTU4) (MTU4) (MTU4) (MTU4) (MTU4) (MTU4) (MTU4)
IMR10 — — CMI1 CMI0 IIC2I — — OEI
(CMT) (CMT) (CMT) (CMT) (IIC2) (IIC2) (POE) (POE)
Note: : Reserved: The read value is not guaranteed.
