Section 12 Bus State Controller (BSC)
Rev. 4.00 Sep. 14, 2005 Page 348 of 982
REJ09B0023-0400
Table 12.12 Relationship between BSZ1, 0, A2/3ROW1, 0, and Address Multiplex Output
(5)-2
Setting
BSZ
1, 0 A2/3
ROW
1, 0 A2/3
COL
1, 0
11 (32 bits) 00 (11 bits) 00 (8 bits)
Output Pin of
This LSI Row Address
Output Cycle Column Address
Output Cycle SDRAM Pin Function
A17 A27 A17
A16 A26 A16
A15 A25 A15
Unused
A14 A24* 2 A24* 2 A13 (BA1)
A13 A23* 2 A23* 2 A12 (BA0)
Specifies bank
A12 A22 A12 A11 Address
A11 A21 L/H* 1 A10/AP Specifies
address/precharge
A10 A20 A10 A9
A9 A19 A9 A8
A8 A18 A8 A7
A7 A17 A7 A6
A6 A16 A6 A5
A5 A15 A5 A4
A4 A14 A4 A3
A3 A13 A3 A2
A2 A12 A2 A1
A1 A11 A1 A0
Address
A0 A10 A0 Unused
Example of connected memory
256-Mbit product (4 Mwords
× 16 bits × 4 banks, column 10 bits product): 1
Notes: 1. L/H is a bit used in the command specification; it is fixed at L or H according to the
access mode.
2. Bank address specification
