Section 25 Electrical Characteristics
Rev. 4.00 Sep. 14, 2005 Page 954 of 982
REJ09B0023-0400
25.3.8 Peripheral
Module Signal Timing
Table 25.9 Peripheral Module Signal Timing
Conditions: V
CC
Q = 3.0 V to 3.6 V, V
CC
= 1.8 V
± 5%, AV
CC
= 3.0 V to 3.6 V,
V
SS
= V
SS
Q = AV
SS
= 0 V, Ta
= −40°C to +85°C
Module Item
Symbol Min.
Max.
Unit Figure(s)
SCIF
Input clock cycle (synchronous)
16
—
t
Pcyc
25.42
(asynchronous)
t
Scyc
4 — t
Pcyc
25.42
Input clock rising time
t
SCKR
—
1.5
t
Pcyc
25.42
Input clock falling time
t
SCKF
—
1.5
t
Pcyc
25.42
Input clock width
t
SCKW
0.4
0.6
t
Scyc
25.42
Transmit data delay time
(synchronous)
t
TXD
—
3
t
Pcyc
+ 15 ns
25.43
Receive data setup time
(synchronous)
t
RXS
4
t
Pcyc
+ 15 —
ns
25.43
Receive data hold time
(synchronous)
t
RXH
100
—
ns
25.43
PORT Output data delay time
t
PORTD
—
100
Input data setup time
t
PORTS2
100
—
Input data hold time
t
PORTH2
100
—
ns 25.44
DMAC
DREQ setup time
t
DREQ
8
—
DREQ hold time
t
DREQH
8
—
25.45
DACK, TEND delay time
t
DACD
—
12
ns
25.46
Note: * t
Pcyc
indicate Pclock cycle.
t
SCKW
t
SCKR
t
SCKF
t
Scyc
SCK
Figure 25.42 SCK Input Clock Timing
