Rules: Register name: The following notation is used for cases when the same or a
similar function, e.g. serial communication, is implemented
on more than one channel:
XXX_N (XXX is the register name and N is the channel
number)
Bit order: The MSB (most significant bit) is on the left and the LSB
(least significant bit) is on the right.
Number notation: Binary is B'xxxx, hexadecimal is H'xxxx, decimal is xxxx.
Signal notation: An overbar is added to a low-active signal:
xxxx
Related Manuals: The latest versions of all related manuals are available from our web site.
Please ensure you have the latest versions of all documents you require.
http://www.renesas.com/eng/
SH7641manuals:
Document Title Document No.
SuperH RISC engine SH7641Hardware Manual This manual
SH-3/SH-3E/SH3-DSP Software Manual REJ09B0171
Users manuals for development tools:
Document Title Document No.
SuperH TM RISC engine C/C++ Compiler,Assembler,Optimizing Linkage
Editor Compiler Package V.9.00 User's Manual
REJ10B0152
SuperH TM RISC engine High-performance Embedded Workshop 3
Users Manual
REJ10B0025
SuperH RISC engine High-Performance Embedded Workshop 3 Tutorial REJ10B0023
Application note:
Document Title Document No.
SuperH RISC engine C/C++ Compiler Package Application Note REJ05B0463
