Section 24 List of Registers
Rev. 4.00 Sep. 14, 2005 Page 878 of 982
REJ09B0023-0400
Register
Abbreviation
Bit
31/23/15/7
Bit
30/22/14/6
Bit
29/21/13/5
Bit
28/20/12/4
Bit
27/19/11/3
Bit
26/18/10/2
Bit
25/17/9/1
Bit
24/16/8/0 Module
IMCR9 IMC7 IMC6 IMC5 IMC4 IMC3 IMC2 IMC1 IMC0 INTC
IMCR10 IMC7 IMC6 IMC5 IMC4 IMC3 IMC2 IMC1 IMC0
IRR0 IRQ7R IRQ6R IRQ5R IRQ4R IRQ3R IRQ2R IRQ1R IRQ0R
ICR1 — IRQE — — IRQ51S IRQ50S IRQ41S IRQ40S
IRQ31S IRQ30S IRQ21S IRQ20S IRQ11S IRQ10S IRQ01S IRQ00S
ICR3 — — — — — — — —
— — — — IRQ71S IRQ70S IRQ61S IRQ60S
IPRC IPR15 IPR14 IPR13 IPR12 IPR11 IPR10 IPR9 IPR8
IPR7 IPR6 IPR5 IPR4 IPR3 IPR2 IPR1 IPR0
IPRD IPR15 IPR14 IPR13 IPR12 IPR11 IPR10 IPR9 IPR8
IPR7 IPR6 IPR5 IPR4 IPR3 IPR2 IPR1 IPR0
IPRE IPR15 IPR14 IPR13 IPR12 IPR11 IPR10 IPR9 IPR8
IPR7 IPR6 IPR5 IPR4 IPR3 IPR2 IPR1 IPR0
IPRJ IPR15 IPR14 IPR13 IPR12 IPR11 IPR10 IPR9 IPR8
IPR7 IPR6 IPR5 IPR4 IPR3 IPR2 IPR1 IPR0
ICR0 NMIL — — — — — — NMIE
— — — — — — — —
IPRB IPR15 IPR14 IPR13 IPR12 IPR11 IPR10 IPR9 IPR8
IPR7 IPR6 IPR5 IPR4 IPR3 IPR2 IPR1 IPR0
BDRB BDB31 BDB30 BDB29 BDB28 BDB27 BDB26 BDB25 BDB24 UBC
BDB23 BDB22 BDB21 BDB20 BDB19 BDB18 BDB17 BDB16
BDB15 BDB14 BDB13 BDB12 BDB11 BDB10 BDB9 BDB8
BDB7 BDB6 BDB5 BDB4 BDB3 BDB2 BDB1 BDB0
BDMRB BDMB31 BDMB30 BDMB29 BDMB28 BDMB27 BDMB26 BDMB25 BDMB24
BDMB23 BDMB22 BDMB21 BDMB20 BDMB19 BDMB18 BDMB17 BDMB16
BDMB15 BDMB14 BDMB13 BDMB12 BDMB11 BDMB10 BDMB9 BDMB8
BDMB7 BDMB6 BDMB5 BDMB4 BDMB3 BDMB2 BDMB1 BDMB0
BRCR — — — — — — — —
— — — — — — — —
SCMFCA SCMFCB SCMFDA SCMFDB PCTE PCBA — —
DBEB PCBB — — SEQ — — ETBE
