Renesas SH7641 User Manual
Page 1026

Rev. 4.00 Sep. 14, 2005 Page 976 of 982
REJ09B0023-0400
Item Page
Revisions
(See Manual for Details)
Section 25 Electrical
Characteristics
Figure 25.37 Synchronous
DRAM Auto-Refreshing
Timing
(WTRP = 1 Cycle, WTRC =
3 Cycles)
Figure 25.38 Synchronous
DRAM Self-Refreshing
Timing
(WTRP = 1 Cycle)
Figure 25.39 Synchronous
DRAM Mode Register
Write Timing (WTRP = 1
Cycle)
Figure 25.41 Synchronous
DRAM Self-Refreshing
Timing in Low-Frequency
Mode
(WTRP = 2 Cycles)
949 to
951
and
953
(Hi-Z)*
3
D31 to D0
Note: 1. An address pin to be connected to pin A10 of SDRAM.
2. Waveform for
DACKn when active low is selected.
3. Pins D31 to D16 with weak keeper are retained as weak keepers.
