Renesas SH7641 - Manual (Page 510)

Section 15 User Debugging Interface (H-UDI)
Rev. 4.00 Sep. 14, 2005 Page 460 of 982
REJ09B0023-0400
Bit Pin Name I/O Bit Pin Name I/O
424 DPLS/PTB8 OUT 392
CS3/PTA3 Control
423 A18 OUT 391
CS2/PTA2 Control
422 A19/PTA8 OUT 390 UCLK/PTB0 Control
421 A20/PTA9 OUT 389 VBUS/PTB1 Control
420 A21/PTA10 OUT 388 SUSPND/PTB2 Control
419 A22/PTA11 OUT 387 XVDATA/PTB3 Control
418 A23/PTA12 OUT 386 TXENL/PTB4 Control
417 A24/PTA13 OUT 385 TXDMNS/PTB5 Control
416 AUDCK OUT 384 TXDPLS/PTB6 Control
415 A25/PTA14 OUT 383 DMNS/PTB7 Control
414 AUDATA0/PTJ8 OUT 382 DPLS/PTB8 Control
413 AUDATA1/PTJ9 OUT 381 A18 Control
412 AUDATA2/PTJ10 OUT 380 A19/PTA8 Control
411 AUDATA3/PTJ11 OUT 379 A20/PTA9 Control
410
AUDSYNC/PTJ12 OUT
378 A21/PTA10 Control
409
IRQ0/PTJ0 OUT
377 A22/PTA11 Control
408
IRQ1/PTJ1 OUT
376 A23/PTA12 Control
407
IRQ2/PTJ2 OUT
375 A24/PTA13 Control
406
IRQ3/PTJ3 OUT
374 AUDCK Control
405
IRQ4/PTJ4 OUT
373 A25/PTA14 Control
404
IRQ5/PTJ5 OUT
372 AUDATA0/PTJ8 Control
403
IRQ6/PTJ6 OUT
371 AUDATA1/PTJ9 Control
402
IRQ7/PTJ7 OUT
370 AUDATA2/PTJ10 Control
401 SCK0/PTH0 OUT 369 AUDATA3/PTJ11 Control
400 D7 Control 368 AUDSYNC/PTJ12 Control
399 D6 Control 367
IRQ0/PTJ0 Control
398 D5 Control 366
IRQ1/PTJ1 Control
397 D4 Control 365
IRQ2/PTJ2 Control
396 D3 Control 364
IRQ3/PTJ3 Control
395 D2 Control 363
IRQ4/PTJ4 Control
394 D1 Control 362
IRQ5/PTJ5 Control
393 D0 Control 361
IRQ6/PTJ6 Control
