Section 18 Multi-Function Timer Pulse Unit (MTU)
Rev. 4.00 Sep. 14, 2005 Page 521 of 982
REJ09B0023-0400
18.2 Input/Output
Pins
Table 18.2 MTU Pin Configuration
Channel Symbol I/O
Function
All
TCLKA
Input
External clock A input pin
(Channel 1 phase counting mode A phase input)
TCLKB
Input
External clock B input pin
(Channel 1 phase counting mode B phase input)
TCLKC
Input
External clock C input pin
(Channel 2 phase counting mode A phase input)
TCLKD
Input
External clock D input pin
(Channel 2 phase counting mode B phase input)
0
TIOC0A
I/O
TGRA_0 input capture input/output compare output/PWM output pin
TIOC0B
I/O
TGRB_0 input capture input/output compare output/PWM output pin
TIOC0C
I/O
TGRC_0 input capture input/output compare output/PWM output pin
TIOC0D
I/O
TGRD_0 input capture input/output compare output/PWM output pin
1
TIOC1A
I/O
TGRA_1 input capture input/output compare output/PWM output pin
TIOC1B
I/O
TGRB_1 input capture input/output compare output/PWM output pin
2
TIOC2A
I/O
TGRA_2 input capture input/output compare output/PWM output pin
TIOC2B
I/O
TGRB_2 input capture input/output compare output/PWM output pin
3
TIOC3A
I/O
TGRA_3 input capture input/output compare output/PWM output pin
TIOC3B
I/O
TGRB_3 input capture input/output compare output/PWM output pin
TIOC3C
I/O
TGRC_3 input capture input/output compare output/PWM output pin
TIOC3D
I/O
TGRD_3 input capture input/output compare output/PWM output pin
4
TIOC4A
I/O
TGRA_4 input capture input/output compare output/PWM output pin
TIOC4B
I/O
TGRB_4 input capture input/output compare output/PWM output pin
TIOC4C
I/O
TGRC_4 input capture input/output compare output/PWM output pin
TIOC4D
I/O
TGRD_4 input capture input/output compare output/PWM output pin
