Section 18 Multi-Function Timer Pulse Unit (MTU)
Rev. 4.00 Sep. 14, 2005 Page 540 of 982
REJ09B0023-0400
Table 18.18 TIORH_0 (Channel 0)
Description
Bit 3
IOA3 Bit 2
IOA2 Bit 1
IOA1 Bit 0
IOA0 TGRA_0
Function
TIOC0A Pin Function
0 0 0 0 Output hold*
1
Output
compare
register
Initial output is 0
0 output at compare match
1 0 Initial output is 0
1 output at compare match
1 Initial output is 0
Toggle output at compare match
1 0 0 Output hold*
1 Initial output is 1
0 output at compare match
1 0 Initial output is 1
1 output at compare match
1 Initial output is 1
Toggle output at compare match
1 0 0 0 Input capture at rising edge
1 Input capture at falling edge
1 X Input capture at both edges
1 X X
Input capture
register
Capture input source is channel 1/count clock
Input capture at TCNT_1 count-up/count-down
[Legend]
X: Don't care
Note: * The low level output is retained until TIOR contents is specified after a power-on reset
and entering standby mode.
