Section 24 List of Registers
Rev. 4.00 Sep. 14, 2005 Page 896 of 982
REJ09B0023-0400
24.3 Register States in Each Operating Mode
Register
Abbreviation Power-On Reset Manual Reset
Software
Standby Module Standby Sleep Module
FRQCR Initialized* 1 Retained Retained  Retained CPG
WTCNT Initialized* 1 Retained Retained  Retained WDT
WTCSR Initialized* 1 Retained Retained  Retained
STBCR Initialized Retained Retained  Retained
STBCR2 Initialized Retained Retained  Retained
Power-down
modes
STBCR3 Initialized Retained Retained  Retained
STBCR4 Initialized Retained Retained  Retained
CCR1 Initialized Initialized Retained Retained Retained Cache
CCR2 Initialized Initialized Retained Retained Retained
INTEVT2 Initialized Initialized Retained Retained Retained
TRA Initialized Initialized Retained Retained Retained
Exception
handling
EXPEVT Initialized Initialized Retained Retained Retained
IPRF Initialized Initialized Retained  Retained INTC
IPRG Initialized Initialized Retained  Retained
IPRH Initialized Initialized Retained  Retained
IPRI Initialized Initialized Retained  Retained
IMR0 Initialized Initialized Retained  Retained
IMR1 Initialized Initialized Retained  Retained
IMR2 Initialized Initialized Retained  Retained
IMR4 Initialized Initialized Retained  Retained
IMR5 Initialized Initialized Retained  Retained
IMR6 Initialized Initialized Retained  Retained
IMR7 Initialized Initialized Retained  Retained
IMR8 Initialized Initialized Retained  Retained
IMR9 Initialized Initialized Retained  Retained
IMR10 Initialized Initialized Retained  Retained
