Section 2 CPU
Rev. 4.00 Sep. 14, 2005 Page 78 of 982
REJ09B0023-0400
System Control Instructions
Table 2.24 System Control Instructions
Instruction
Instruction Code
Operation
Execution
States
T Bit
CLRMAC 0000000000101000
0
→ MACH, MACL
1
—
CLRS 0000000001001000
0
→ S
1
—
CLRT 0000000000001000
0
→ T
1
0
LDC Rm,SR
0100mmmm00001110
Rm
→ SR
6
LSB
LDC Rm,GBR
0100mmmm00011110
Rm
→ GBR
4
—
LDC Rm,VBR
0100mmmm00101110
Rm
→ VBR
4
—
LDC Rm,SSR
0100mmmm00111110
Rm
→ SSR
4
—
LDC Rm,SPC
0100mmmm01001110
Rm
→ SPC
4
—
LDC Rm,R0_BANK 0100mmmm10001110
Rm
→ R0_BANK
4
—
LDC Rm,R1_BANK 0100mmmm10011110
Rm
→ R1_BANK
4
—
LDC Rm,R2_BANK 0100mmmm10101110
Rm
→ R2_BANK
4
—
LDC Rm,R3_BANK 0100mmmm10111110
Rm
→ R3_BANK
4
—
LDC Rm,R4_BANK 0100mmmm11001110
Rm
→ R4_BANK
4
—
LDC Rm,R5_BANK 0100mmmm11011110
Rm
→ R5_BANK
1
—
LDC Rm,R6_BANK 0100mmmm11101110
Rm
→ R6_BANK
4
—
LDC Rm,R7_BANK 0100mmmm11111110
Rm
→ R7_BANK
4
—
LDC.L @Rm+,SR
0100mmmm00000111
(Rm)
→ SR, Rm + 4 → Rm
8
LSB
LDC.L @Rm+,GBR
0100mmmm00010111
(Rm)
→ GBR, Rm + 4 → Rm
4
—
LDC.L @Rm+,VBR
0100mmmm00100111
(Rm)
→ VBR, Rm + 4 → Rm
4
—
LDC.L @Rm+,SSR
0100mmmm00110111
(Rm)
→ SSR, Rm + 4 → Rm
4
—
LDC.L @Rm+,SPC
0100mmmm01000111
(Rm)
→ SPC, Rm + 4 → Rm
4
—
LDC.L @Rm+,
R0_BANK
0100mmmm10000111
(Rm)
→ R0_BANK,
Rm + 4
→ Rm
4 —
LDC.L @Rm+,
R1_BANK
0100mmmm10010111
(Rm)
→ R1_BANK,
Rm + 4
→ Rm
4 —
LDC.L @Rm+,
R2_BANK
0100mmmm10100111
(Rm)
→ R2_BANK,
Rm + 4
→ Rm
4 —
LDC.L @Rm+,
R3_BANK
0100mmmm10110111
(Rm)
→ R3_BANK,
Rm + 4
→ Rm
4 —
