Section 24 List of Registers
Rev. 4.00 Sep. 14, 2005 Page 869 of 982
REJ09B0023-0400
Register Name Abbreviation Bit No. Address Module Access States
Refresh timer control/status register RTCSR 16 H'A4FD0048 BSC 32* 3
Refresh timer counter RTCNT 16 H'A4FD004C 32* 3
Refresh time constant register RTCOR 16 H'A4FD0050 32* 3
Reset wait counter RWTCNT 16 H'A4FD0054 32* 3
— — — — — —
DMA source address register_0 SAR_0 32 H'A401 0020 DMAC 16/32
DMA destination address register_0 DAR_0 32 H'A401 0024 16/32
DMA transfer count register_0 DMATCR_0 32 H'A401 0028 16/32
DMA channel control register_0 CHCR_0 32 H'A401 002C 8/16/32
DMA source address register_1 SAR_1 32 H'A401 0030 16/32
DMA destination address register_1 DAR_1 32 H'A401 0034 16/32
DMA transfer count register_1 DMATCR_1 32 H'A401 0038 16/32
DMA channel control register _1 CHCR_1 32 H'A401 003C 8/16/32
DMA source address register_2 SAR_2 32 H'A401 0040 16/32
DMA destination address register_2 DAR_2 32 H'A401 0044 16/32
DMA transfer count register_2 DMATCR_2 32 H'A401 0048 16/32
DMA channel control register_2 CHCR_2 32 H'A401 004C 8/16/32
DMA source address register_3 SAR_3 32 H'A401 0050 16/32
DMA destination address register_3 DAR_3 32 H'A401 0054 16/32
DMA transfer count register_3 DMATCR_3 32 H'A401 0058 16/32
DMA channel control register_3 CHCR_3 32 H'A401 005C 8/16/32
DMA operation register DMAOR 32 H'A401 0060 8/16/32
DMA extension resource selector 0 DMARS0 16 H'A409 0000 16
DMA extension resource selector 1 DMARS1 16 H'A409 0004 16
— — — — — —
Instruction register SDIR 16 H'A100 0200 H-UDI 16
ID Register SDIDH 16 H'A100 0214 16/32
ID Register SDIDL 16 H'A100 0216 16
— — — — — —
