Section 12 Bus State Controller (BSC)
Rev. 4.00 Sep. 14, 2005 Page 395 of 982
REJ09B0023-0400
BSC Register Setting CPU Access DMAC Access
CSnBCR
Idle
Setting CS3WCR.
WTRP
Setting CS3WCR.
TRWL
Setting
Read to
Read Write to
Write Read to
Write Write to
Read Read to
Write Write to
Read
4 2 0 5/5/5/5 4/4/4/4 5/5/5/5 4/4/4/4 5 4
4 2 1 5/5/5/5 4/4/4/4 5/5/5/5 4/4/4/4 5 4
4 2 2 5/5/5/5 4/4/4/4 5/5/5/5 4/4/4/4 5 4
4 2 3 5/5/5/5 5/5/5/5 5/5/5/5 5/5/5/5 5 5
4 3 0 5/5/5/5 4/4/4/4 5/5/5/5 4/4/4/4 5 4
4 3 1 5/5/5/5 4/4/4/4 5/5/5/5 4/4/4/4 5 4
4 3 2 5/5/5/5 5/5/5/5 5/5/5/5 5/5/5/5 5 5
4 3 3 5/5/5/5 6/6/6/6 5/5/5/5 6/6/6/6 5 6
n (n>=6)   All n+1 n/n/n/n All n+1 n/n/n/n n+1 n
Notes: The minimum number of idle cycles in CPU Access is described sequentially for I φ:Bφ
(4:1/3:1/2:1/1:1).
1. DMAC is operated by B
φ. The minimum number of idle cycles is not affected by
changing a clock ratio.
