Renesas SH7641 User Manual
Page 122
Section 2 CPU
Rev. 4.00 Sep. 14, 2005 Page 72 of 982
REJ09B0023-0400
Instruction
Instruction Code
Operation
Execution
States
T Bit
MOV.L Rm,@(R0,Rn)
0000nnnnmmmm0110
Rm
→ (R0 + Rn)
1
—
MOV.B @(R0,Rm),Rn
0000nnnnmmmm1100
(R0 + Rm)
→ Sign extension
→ Rn
1 —
MOV.W @(R0,Rm),Rn
0000nnnnmmmm1101
(R0 + Rm)
→ Sign extension
→ Rn
1 —
MOV.L @(R0,Rm),Rn
0000nnnnmmmm1110
(R0 + Rm)
→ Rn
1
—
MOV.B R0,@(disp,GBR)
11000000dddddddd
R0
→ (disp + GBR)
1
—
MOV.W R0,@(disp,GBR)
11000001dddddddd
R0
→ (disp × 2 + GBR)
1
—
MOV.L R0,@(disp,GBR)
11000010dddddddd
R0
→ (disp × 4 + GBR)
1
—
MOV.B @(disp,GBR),R0
11000100dddddddd
(disp + GBR)
→ Sign
extension
→ R0
1 —
MOV.W @(disp,GBR),R0
11000101dddddddd
(disp
× 2 + GBR) →
Sign extension
→ R0
1 —
MOV.L @(disp,GBR),R0
11000110dddddddd
(disp
× 4 + GBR) → R0 1
—
MOVA @(disp,PC),R0
11000111dddddddd
disp
× 4 + PC → R0
1
—
MOVT Rn
0000nnnn00101001
T
→ Rn
1
—
SWAP.B Rm,Rn
0110nnnnmmmm1000
Rm
→ Swap lowest two
bytes
→ Rn
1 —
SWAP.W Rm,Rn
0110nnnnmmmm1001
Rm
→ Swap two consecutive
words
→ Rn
1 —
XTRCT Rm,Rn
0010nnnnmmmm1101
Middle 32 bits of Rm and
Rn
→ Rn
1
