Section 24 List of Registers
Rev. 4.00 Sep. 14, 2005 Page 871 of 982
REJ09B0023-0400
Register Name Abbreviation Bit No. Address Module Access States
Timer output control register TOCR 8 H'A449 000B MTU 8/16/32
Timer gate control register TGCR 8 H'A449 000D 8
Timer counter_3 TCNT_3 16 H'A449 0010 16/32
Timer counter_4 TCNT_4 16 H'A449 0012 16/32
Timer cycle data register TCDR 16 H'A449 0014 16/32
Timer dead time data register TDDR 16 H'A449 0016 16/32
Timer general register A_3 TGRA_3 16 H'A449 0018 16/32
Timer general register B_3 TGRB_3 16 H'A449 001A 16/32
Timer general register A_4 TGRA_4 16 H'A449 001C 16/32
Timer general register B_4 TGRB_4 16 H'A449 001E 16/32
Timer subcounter TCNTS 16 H'A449 0020 16/32
Timer cycle buffer register TCBR 16 H'A449 0022 16/32
Timer general register C_3 TGRC_3 16 H'A449 0024 16/32
Timer general register D_3 TGRD_3 16 H'A449 0026 16/32
Timer general register C_4 TGRC_4 16 H'A449 0028 16/32
Timer general register D_4 TGRD_4 16 H'A449 002A 16/32
Timer status register_3 TSR_3 8 H'A449 002C 8/16
Timer status register_4 TSR_4 8 H'A449 002D 8/16
Timer start register TSTR 8 H'A449 0040 8/16
Timer synchro register TSYR 8 H'A449 0041 8/16
Timer control register_0 TCR_0 8 H'A449 0060 8/16/32
Timer mode register_0 TMDR_0 8 H'A449 0061 8/16/32
Timer I/O control register H_0 TIORH_0 8 H'A449 0062 8/16/32
Timer I/O control register L_0 TIORL_0 8 H'A449 0063 8/16/32
Timer interrupt enable register_0 TIER_0 8 H'A449 0064 8/16/32
Timer status register_0 TSR_0 8 H'A449 0065 8/16/32
Timer counter_0 TCNT_0 16 H'A449 0066 16
Timer general register A_0 TGRA_0 16 H'A449 0068 16/32
Timer general register B_0 TGRB_0 16 H'A449 006A 16/32
Timer general register C_0 TGRC_0 16 H'A449 006C 16/32
Timer general register D_0 TGRD_0 16 H'A449 006E 16/32
