Section 12 Bus State Controller (BSC)
Rev. 4.00 Sep. 14, 2005 Page 272 of 982
REJ09B0023-0400
12.2 Input/Output Pins
Table 12.1 shows pin configuration of the BSC.
Table 12.1 Pin Configuration
Name I/O Function
A25 to A0 Output Address bus
D31 to D0 I/O Data bus
BS
Output Bus cycle start
CS0, CS2 to CS4 Output Chip
select
CS5A Output
Chip select
Active only for address map 1
RD/
WR Output
Read/write
Connects to
WE pins when SDRAM or byte-selection SRAM is
connected.
RD
Output Read pulse signal (read data output enable signal)
WE3/ICIOWR/AH Output Indicates that D31 to D24 are being written to.
Connected to the byte select signal when a byte-selection SRAM is
connected.
Functions as the address hold signal when the MPX-IO is used.
Functions as the selection signals for D31 to D24 when SDRAM is
connected.
WE2/ICIRD
Output Indicates that D23 to D16 are being written to.
Connected to the byte select signal when a byte-selection SRAM is
connected.
Functions as the selection signals for D23 to D16 when SDRAM is
connected.
WE1/WE
Output Indicates that D15 to D8 are being written to.
Connected to the byte select signal when a byte-selection SRAM is
connected.
Functions as the selection signals for D15 to D8 when SDRAM is
connected.
