Appendix

Rev. 4.00 Sep. 14, 2005 Page 970 of 982

REJ09B0023-0400

[Legend]

I: Input

I+:

Input with weak keeper

I++: Input with pull-up MOS

O: Output

L:

Low level output

H: High

level

output

Z:

Hi-Z (The pin must not be open since the intermediate level at this pin caused a pass though
current in the LSI.)

Z+:

Hi-Z with weak keeper

Z++: Hi-Z with pull-up MOS

K:

Input becomes Hi-Z, output retains state

Notes: 1. The EXTAL pin must be pulled up and the XTAL pin must be open.

2. Controlled by the HIZCNT bit in the common control register of the BSC.

3. Controlled by the HIZMEM bit in the common control register of the BSC.

4. Controlled by the HIZ bit in the standby control register.

5. The pin must not be open since the intermediate level at this pin causes the path

though current in the LSI.

6. The data register of the I/O port can be written to.

7. Hi-Z when the TAP controller of the H-UDI is neither Shift-DR nor Shift-IR state.

8. When the H-UDI is not used, pins

ASEMD0, TCK, TDI, and TMS must be pulled up, the

TDO and

ASEBRKAK pins must be open, and the TRST pin must be connected to the

RESETP pin or ground.
For use of emulators, the board must be designed following instructions in the emulator
manual.
