Section 15 User Debugging Interface (H-UDI)
Rev. 4.00 Sep. 14, 2005 Page 464 of 982
REJ09B0023-0400
Bit Pin Name I/O Bit Pin Name I/O
168 D28/PTD12 IN 136
BREQ/PTC6 Control
167 D27/PTD11 IN 135
BACK/PTC7 Control
166 D26/PTD10 IN 134
ASEBRKAK/PTC13 Control
165
DREQ0/PTC9 OUT
133
CS6B/PTC4 Control
164
DREQ1/PTC10 OUT
132
CS6A/PTC3 Control
163 STATUS0/PTC14 OUT 131
CS5B/PTC2 Control
162 STATUS1/PTC15 OUT 130
CS5A/PTC1 Control
161
BREQ/PTC6 OUT
129
CS4/PTC0 Control
160
BACK/PTC7 OUT
128
CS0
Control
159
ASEBRKAK/PTC13 OUT 127 BS
Control
158
CS6B/PTC4 OUT
126
TEND/PTC8 Control
157
CS6A/PTC3 OUT
125
FRAME/PTC5 Control
156
CS5B/PTC2 OUT
124
RD
Control
155
CS5A/PTC1 OUT
123
DACK0/PTC11 Control
154
CS4/PTC0 OUT
122
DACK1/PTC12 Control
153
CS0
OUT 121 D31/PTD15 Control
152
BS
OUT 120 D30/PTD14 Control
151
TEND/PTC8 OUT
119 D29/PTD13 Control
150
FRAME/PTC5 OUT
118 D28/PTD12 Control
149
RD
OUT 117 D27/PTD11 Control
148
DACK0/PTC11 OUT
116 D26/PTD10 Control
147
DACK1/PTC12 OUT
115 D25/PTD9 IN
146 D31/PTD15 OUT 114 D24/PTD8 IN
145 D30/PTD14 OUT 113 D23/PTD7 IN
144 D29/PTD13 OUT 112 D22/PTD6 IN
143 D28/PTD12 OUT 111 D21/PTD5 IN
142 D27/PTD11 OUT 110 D20/PTD4 IN
141 D26/PTD10 OUT 109 D19/PTD3 IN
140
DREQ0/PTC9 Control
108 D18/PTD2 IN
139
DREQ1/PTC10 Control
107 D17/PTD1 IN
138 STATUS0/PTC14 Control 106 D16/PTD0 IN
137 STATUS1/PTC15 Control 105
CASU/PTA5 IN
