Section 15 User Debugging Interface (H-UDI)
Rev. 4.00 Sep. 14, 2005 Page 463 of 982
REJ09B0023-0400
Bit Pin Name I/O Bit Pin Name I/O
232 TIOC2B/PTE8 Control 200 AN2/PTG2 IN
231 TIOC2A/PTE9 Control 199 AN3/PTG3 IN
230 TIOC1B/PTE10 Control 198 AN4/PTG4 IN
229 TIOC1A/PTE11 Control 197 AN5/PTG5 IN
228 TIOC0D/PTE12 Control 196 AN6/PTG6 IN
227 TIOC0C/PTE13 Control 195 AN7/PTG7 IN
226 TIOC0B/PTE14 Control 194
DREQ0/PTC9 IN
225 TIOC0A/PTE15 Control 193
DREQ1/PTC10 IN
224 TCLKD/PTF8 Control 192 STATUS0/PTC14 IN
223 TCLKC/PTF9 Control 191 STATUS1/PTC15 IN
222 TCLKB/PTF10 Control 190
BREQ/PTC6 IN
221 TCLKA/PTF11 Control 189
BACK/PTC7 IN
220
POE0/PTF12 Control
188 *VccQ IN
219
POE1/PTF13 Control
187 *VccQ IN
218
POE2/PTF14 Control
186
ASEBRKAK/PTC13 IN
217
POE3/PTF15 Control
185 MD3 IN
216 PTF0 Control 184 MD2 IN
215 PTF1 Control 183 *VccQ IN
214 PTF2 Control 182 MD0 IN
213 PTF3 Control 181
CS6B/PTC4 IN
212 PTF4 Control 180
CS6A/PTC3 IN
211 PTF5 Control 179
CS5B/PTC2 IN
210 PTF6 Control 178
CS5A/PTC1 IN
209 PTF7 Control 177
CS4/PTC0 IN
208 PTG8 Control 176
WAIT
IN
207 PTG9/SCL Control 175
TEND/PTC8 IN
206 PTG10/SDA Control 174
FRAME/PTC5 IN
205 PTG11 Control 173
DACK0/PTC11 IN
204 PTG12 Control 172
DACK1/PTC12 IN
203 PTG13 Control 171 D31/PTD15 IN
202 AN0/PTG0 IN 170 D30/PTD14 IN
201 AN1/PTG1 IN 169 D29/PTD13 IN
