Section 19 Serial Communication Interface with FIFO (SCIF)
Rev. 4.00 Sep. 14, 2005 Page 710 of 982
REJ09B0023-0400
P
φ
(MHz)
24.576 28.7 30 33
Bit Rate
(bits/s)
n
N Error
(
% )
n
N Error
(
% )
n
N Error
(
% )
n
N Error
(
% )
110 3 108 0.08 3 126 0.31 3 132 0.13 3 145 0.33
150 3 79 0.00 3 92 0.46 3 97 –0.35 3 106 0.39
300 2 159 0.00 2 186 –0.08 2 194 0.16 2 214 -0.07
600 2 79 0.00 2 92 0.46 2 97 –0.35 2 106 0.39
1200 1 159 0.00 1 186 –0.08 1 194 0.16 1 214 -0.07
2400 1 79 0.00 1 92 0.46 1 97 –0.35 1 106 0.39
4800 0 159 0.00 0 186 –0.08 0 194 –1.36 0 214 -0.07
9600 0 79 0.00 0 92 0.46 0 97 –0.35 0 106 0.39
19200 0 39 0.00 0 46 –0.61 0 48 –0.35 0 53 -0.54
31250 0 24 –1.70 0 28 –1.03 0 29 0.00 0 32 0.00
38400 0 19 0.00 0 22 1.55 0 23 1.73 0 26 -0.54
Note: Settings with an error of 1% or less are recommended.
