Section 24 List of Registers
Rev. 4.00 Sep. 14, 2005 Page 868 of 982
REJ09B0023-0400
Register Name Abbreviation Bit No. Address Module Access States
Break data register B BDRB 32 H'A4FFFF90 UBC 32
Break data mask register B BDMRB 32 H'A4FFFF94 32
Break control register BRCR 32 H'A4FFFF98 32
Execution Times Break Register BETR 16 H'A4FFFF9C 16
Break address register B BARB 32 H'A4FFFFA0 32
Break address mask register B BAMRB 32 H'A4FFFFA4 32
Break bus cycle register B BBRB 16 H'A4FFFFA8 16
Branch source register BRSR 32 H'A4FFFFAC 32
Break address register A BARA 32 H'A4FFFFB0 32
Break address mask register A BAMRA 32 H'A4FFFFB4 32
Break bus cycle register A BBRA 16 H'A4FFFFB8 16
Branch destination register BRDR 32 H'A4FFFFBC 32
— — — — — —
Common control register CMNCR 32 H'A4FD0000 BSC 32
Bus control register for area 0 CS0BCR 32 H'A4FD0004 32
Bus control register for area 2 CS2BCR 32 H'A4FD0008 32
Bus control register for area 3 CS3BCR 32 H'A4FD000C 32
Bus control register for area 4 CS4BCR 32 H'A4FD0010 32
Bus control register for area 5A CS5ABCR 32 H'A4FD0014 32
Bus control register for area 5B CS5BBCR 32 H'A4FD0018 32
Bus control register for area 6A CS6ABCR 32 H'A4FD001C 32
Bus control register for area 6B CS6BBCR 32 H'A4FD0020 32
Wait control register for area 0 CS0WCR 32 H'A4FD0024 32
Wait control register for area 2 CS2WCR 32 H'A4FD0028 32
Wait control register for area 3 CS3WCR 32 H'A4FD002C 32
Wait control register for area 4 CS4WCR 32 H'A4FD0030 32
Wait control register for area 5A CS5AWCR 32 H'A4FD0034 32
Wait control register for area 5B CS5BWCR 32 H'A4FD0038 32
Wait control register for area 6A CS6AWCR 32 H'A4FD003C 32
Wait control register for area 6B CS6BWCR 32 H'A4FD0040 32
SDRAM control register SDCR 32 H'A4FD0044 32
