Appendix

Rev. 4.00 Sep. 14, 2005 Page 971 of 982

REJ09B0023-0400

A.2

When I/O Port is Selected

Table A.2

Pin States in Reset State, Power Down Mode, and Bus-Released States When
I/O Port is Selected

Reset State

Power Down Mode

Pin Name

Power-On

Manual

Software
Standby Sleep

Bus-Released
Reset

PTA[14:0] Z+

I+/O

Z+/K* I+/O I+/O

PTB[8:0] Z+

I+/O

Z+/K* I+/O I+/O

PTC[15,14,12:0] Z+

I+/O

Z+/K* I+/O I+/O

PTC[13] O

I+/O

Z+/K* I+/O I+/O

PTD[15:0] Z+

I+/O

Z+/K* I+/O I+/O

PTE[15:0] Z+

I+/O

Z+/K* I+/O I+/O

PTF[15:0] Z+

I+/O

Z+/K* I+/O I+/O

PTG[13:11,8] Z+ I+/O Z+/K* I+/O I+/O

PTG[10:9] Z I/O

Z+/K* I/O I/O

PTG[7:0] Z I Z I

I

PTH[14:0] Z+

I+/O

Z+/K* I+/O I+/O

PTJ[12:0] Z+

I+/O

Z+/K* I+/O I+/O

[Legend]

I: Input

I+:

Input with weak keeper

O: Output

Z:

Hi-Z (The pin must not be open since the intermediate level at this pin causes a path though
current in the LSI.)

Z+: Hi-Z with weak keeper

K:

Input becomes Hi-Z, output retains state

Note: * Controlled by the HIZ bit in the standby control register.
