Section 24 List of Registers
Rev. 4.00 Sep. 14, 2005 Page 888 of 982
REJ09B0023-0400
Register
Abbreviation
Bit
31/23/15/7
Bit
30/22/14/6
Bit
29/21/13/5
Bit
28/20/12/4
Bit
27/19/11/3
Bit
26/18/10/2
Bit
25/17/9/1
Bit
24/16/8/0 Module
TGRB_3 MTU
TGRA_4
TGRB_4
TCNTS
TCBR
TGRC_3
TGRD_3
TGRC_4
TGRD_4
TSR_3 TCFD — — TCFV TGFD TGFC TGFB TGFA
TSR_4 TCFD — — TCFV TGFD TGFC TGFB TGFA
TSTR CST4 CST3 — — — CST2 CST1 CST0
TSYR SYNC4 SYNC3 — — — SYNC2 SYNC1 SYNC0
TCR_0 CCLR2 CCLR1 CCLR0 CKEG1 CKEG0 TPSC2 TPSC1 TPSC0
TMDR_0 — — BFB BFA MD3 MD2 MD1 MD0
TIORH_0 IOB3 IOB2 IOB1 IOB0 IOA3 IOA2 IOA1 IOA0
TIORL_0 IOD3 IOD2 IOD1 IOD0 IOC3 IOC2 IOC1 IOC0
TIER_0 TTGE TGFASEL — TCIEV TGIED TGIEC TGIEB TGIEA
TSR_0 — — — TCFV TGFD TGFC TGFB TGFA
TCNT_0
