Section 2 CPU

Rev. 4.00 Sep. 14, 2005 Page 41 of 982

REJ09B0023-0400

Table 2.4

DSR Register Bits

Bits Name

(Abbreviation)

Function

31 to 8

Reserved bits

0: Always read as 0; always use 0 as the write value

Signed Greater Than bit (GT) Indicates that the operation result is positive (except 0),

or that operand 1 is greater than operand 2

1: Operation result is positive, or operand 1 is greater

than operand 2

Zero bit (Z)

Indicates that the operation result is zero (0), or that
operand 1 is equal to operand 2

1: Operation result is zero (0), or operands are equal

Negative bit (N)

Indicates that the operation result is negative, or that
operand 1 is smaller than operand 2

1: Operation result is negative, or operand 1 is smaller

than operand 2

Overflow bit (V)

Indicates that the operation result has overflowed

1: Operation result has overflowed

3 to 1

Condition Select bits (CS)

Designate the mode for selecting the operation result
status to be set in the DC bit

Do not set these bits to 110 or 111

000: Carry/borrow mode

001: Negative value mode

010: Zero mode

011: Overflow mode

100: Signed greater mode

101: Signed greater than or equal to mode

DSP Condition bit (DC)

Sets the status of the operation result in the mode
designated by the CS bits

0: Designated mode status has not occurred (false)

1: Designated mode status has occurred

Note: After execution of a PADDC/PSUBC instruction, the DC bit sets the status of the operation

result in carry/borrow mode regardless of the CS bits.
