Section 18 Multi-Function Timer Pulse Unit (MTU)
Rev. 4.00 Sep. 14, 2005 Page 631 of 982
REJ09B0023-0400
Compare
match buffer
signal
Compare
match signal
Write signal
Address
P φ
Buffer register
address
Buffer register
TGR write cycle
T1 T2
M TGR
N M
Buffer register write data
Figure 18.74 Conflict between Buffer Register Write and Compare Match (Channel 0)
P φ
Address
Write signal
Compare match
signal
Compare match
buffer signal
TGR write cycle
T1 T2
Buffer register
address
N
N M
Buffer register write data
Buffer register
TGR
Figure 18.75 Conflict between Buffer Register Write and Compare Match
(Channels 3 and 4)
