Section 2 CPU
Rev. 4.00 Sep. 14, 2005 Page 83 of 982
REJ09B0023-0400
Instruction
Instruction Code
Operation Execution
States
T Bit
STS.L DSR,@-Rn 0100nnnn01100010 Rn – 4 → Rn, DSR → (Rn) 1 
STS.L A0,@-Rn 0100nnnn01110010 Rn – 4 → Rn, A0 → (Rn) 1 
STS.L X0,@-Rn 0100nnnn10000010 Rn – 4
→ Rn, X0 → (Rn) 1 
STS.L X1,@-Rn 0100nnnn10010010 Rn – 4
→ Rn, X1 → (Rn) 1 
STS.L Y0,@-Rn 0100nnnn10100010 Rn – 4 → Rn, Y0 → (Rn) 1 
STS.L Y1,@-Rn 0100nnnn10110010 Rn – 4 → Rn, Y1 → (Rn) 1 
STC.L MOD,@-Rn 0100nnnn01010011 Rn – 4 → Rn, MOD → (Rn) 1 
STC.L RS,@-Rn 0100nnnn01100011 Rn – 4 → Rn, RS → (Rn) 1 
STC.L RE,@-Rn 0100nnnn01110011 Rn – 4
→ Rn, RE → (Rn) 1 
LDS.L @Rn+,DSR 0100nnnn01100110 (Rn)
→ DSR, Rn + 4 → Rn 1 
LDS.L @Rn+,A0 0100nnnn01110110 (Rn)
→ A0, Rn + 4 → Rn 1 
LDS.L @Rn+,X0 0100nnnn10000110 (Rn) → X0, Rn + 4 → Rn 1 
LDS.L @Rn+,X1 0100nnnn10010110 (Rn) → X1, Rn + 4 → Rn 1 
LDS.L @Rn+,Y0 0100nnnn10100110 (Rn) → Y0, Rn + 4 → Rn 1 
LDS.L @Rn+,Y1 0100nnnn10110110 (Rn) → Y1, Rn + 4 → Rn 1 
LDC.L @Rn+,MOD 0100nnnn01010111 (Rn)
→ MOD, Rn + 4 → Rn 4 
LDC.L @Rn+,RS 0100nnnn01100111 (Rn)
→ RS, Rn + 4 → Rn 4 
LDC.L @Rn+,RE 0100nnnn01110111 (Rn) → RE, Rn + 4 → Rn 4 
LDS Rn,DSR 0100nnnn01101010 Rn → DSR 1 
LDS Rn,A0 0100nnnn01111010 Rn → A0 1 
LDS Rn,X0 0100nnnn10001010 Rn → X0 1 
LDS Rn,X1 0100nnnn10011010 Rn → X1 1 
LDS Rn,Y0 0100nnnn10101010 Rn
→ Y0 1 
LDS Rn,Y1 0100nnnn10111010 Rn
→ Y1 1 
LDC Rn,MOD 0100nnnn01011110 Rn
→ MOD 4 
LDC Rn,RS 0100nnnn01101110 Rn → RS 4 
LDC Rn,RE 0100nnnn01111110 Rn → RE 4 
