Section 22 Pin Function Controller (PFC)
Rev. 4.00 Sep. 14, 2005 Page 838 of 982
REJ09B0023-0400
22.1.10 Port H Control Register (PHCR)
PHCR is a 32-bit readable/writable register that selects the pin functions. PHCR is initialized to
H'00000000 by a power-on reset, and it is not initialized by a manual reset, in standby mode, or in
sleep mode.
Bit Bit Name
Initial
Value R/W
Description
31, 30  All 0 R Reserved
These bits are always read as 0. The write value should
always be 0.
29
28
PH14MD2
PH14MD1
0
0
R/W
27
26
PH13MD2
PH13MD1
0
0
R/W
25
24
PH12MD2
PH12MD2
0
0
R/W
23
22
PH11MD2
PH11MD2
0
0
R/W
21
20
PH10MD2
PH10MD2
0
0
R/W
19
18
PH9MD2
PH9MD2
0
0
R/W
17
16
PH8MD2
PH8MD2
0
0
R/W
15
14
PH7MD2
PH7MD2
0
0
R/W
13
12
PH6MD2
PH6MD2
0
0
R/W
11
10
PH5MD2
PH5MD2
0
0
R/W
9
8
PH4MD2
PH4MD2
0
0
R/W
PHn Mode 2 and 1
The combination of bits PHnMD2 and PHnMD1controls
the pin functions. (n = 0 to 14)
00: Port input
01: Port output
10: Reserved (When set, correct operation cannot be
guaranteed.)
11: Other functions (see table22.1.)
