Section 22 Pin Function Controller (PFC)
Rev. 4.00 Sep. 14, 2005 Page 820 of 982
REJ09B0023-0400
Port Port Function (Related Module) Other Function (Related Module)
C PTC15 input/output (port) STATUS1 output (CPG)
PTC14 input/output (port) STATUS0 output (CPG)
PTC13 input/output (port)
ASEBRKAK output (CPU)
PTC12 input/output (port)
DACK1 output (DMAC)
PTC11 input/output (port)
DACK0 output (DMAC)
PTC10 input/output (port)
DREQ1 input (DMAC)
PTC9 input/output (port)
DREQ0 input (DMAC)
PTC8 input/output (port)
TEND output (DMAC)
PTC7 input/output (port)
BACK output (BSC)
PTC6 input/output (port)
BREQ input (BSC)
PTC5 input/output (port)
FRAME output (BSC)
PTC4 input/output (port)
CS6B output (BSC)
PTC3 input/output (port)
CS6A output (BSC)
PTC2 input/output (port)
CS5B output (BSC)
PTC1 input/output (port)
CS5A output (BSC)
PTC0 input/output (port)
CS4 output (BSC)
D PTD15 input/output (port) D31 input/output (data bus)
PTD14 input/output (port) D30 input/output (data bus)
PTD13 input/output (port) D29 input/output (data bus)
PTD12 input/output (port) D28 input/output (data bus)
PTD11 input/output (port) D27 input/output (data bus)
PTD10 input/output (port) D26 input/output (data bus)
PTD9 input/output (port) D25 input/output (data bus)
PTD8 input/output (port) D24 input/output (data bus)
PTD7 input/output (port) D23 input/output (data bus)
PTD6 input/output (port) D22 input/output (data bus)
PTD5 input/output (port) D21 input/output (data bus)
PTD4 input/output (port) D20 input/output (data bus)
PTD3 input/output (port) D19 input/output (data bus)
PTD2 input/output (port) D18 input/output (data bus)
PTD1 input/output (port) D17 input/output (data bus)
PTD0 input/output (port) D16 input/output (data bus)
