Section 18 Multi-Function Timer Pulse Unit (MTU)
Rev. 4.00 Sep. 14, 2005 Page 678 of 982
REJ09B0023-0400
Bit Bit Name
Initial
value R/W Description
3
2
POE1M1
POE1M0
0
0
R/W
R/W
POE1 mode 1, 0
These bits select the input mode of the
POE1 pin.
00: Accept request on falling edge of
POE1 input
01: Accept request when
POE1 input has been
sampled for 16 P φ/8 clock pulses, and all are low
level.
10: Accept request when
POE1 input has been
sampled for 16 P φ/16 clock pulses, and all are
low level.
11: Accept request when
POE1 input has been
sampled for 16 P φ/128 clock pulses, and all are
low level.
1
0
POE0M1
POE0M0
0
0
R/W
R/W
POE0 mode 1, 0
These bits select the input mode of the
POE0 pin.
00: Accept request on falling edge of
POE0 input
01: Accept request when
POE0 input has been
sampled for 16 P
φ/8 clock pulses, and all are low
level.
10: Accept request when
POE0 input has been
sampled for 16 P φ/16 clock pulses, and all are
low level.
11: Accept request when
POE0 input has been
sampled for 16 P φ/128 clock pulses, and all are
low level.
Note: * The write value should always be 0.
