Section 1 Overview

Rev. 4.00 Sep. 14, 2005 Page 20 of 828

REJ09B0023-0400

Classification Symbol

I/O Name

Function

Bus control

RD/

WR O

Read/write

Read/write

signal

BS

O

Bus start

Bus-cycle start

WE3/DQMUU/

AH

O

Byte specification Indicates that bits 31 to 24 of the

data in the external memory or
device are being written.

Selects D31 to D24 when SDRAM is
connected.

Address hold signal for address/data
multiplexed I/O.

WE2/DQMUL

O

Byte specification Indicates that bits 23 to 16 of the

data in the external memory or
device are being written.

Selects D23 to D16 when SDRAM is
connected.

WE1/DQMLU O Byte

specification Indicates that bits 15 to 8 of the data

in the external memory or device are
being written.

Selects D15 to D8 when SDRAM is
connected.

WE0/DQMLL O Byte

specification Indicates that bits 7 to 0 of the data

in the external memory or device are
being written.

Selects D7 to D0 when SDRAM is
connected.

RASU, RASL

O

RAS

Connected to the

RAS pin when the

SDRAM is connected.

CASU, CASL

O

CAS

Connected to the

CAS pin when the

SDRAM is connected.

CKE

O

CK enable

Connected to the CKE pin when the
SDRAM is connected.

FRAME

O

FRAME signal

Connects the

FRAME signal for the

burst MPX-IO interface.

WAIT

I

Wait

When active, inserts a wait cycle into
the bus cycles during access to the
external space.
