Section 1 Overview
Rev. 4.00 Sep. 14, 2005 Page 12 of 828
REJ09B0023-0400
No.
(BGA256) Pin
Name Description
W9 TIOC3C/PTE[5] Timer input output 3C/Port E
U9 TIOC3A/PTE[7] Timer input output 3A/Port E
Y9 TIOC2B/PTE[8] Timer input output 2B/Port E
V10 Vss Ground (0V)
W10 TIOC2A/PTE[9] Timer input output 2A/Port E
U10 Vcc Power supply (1.8V)
Y10 TIOC1B/PTE[10] Timer input output 1B/Port E
Y11 TIOC1A/PTE[11] Timer input output 1A/Port E
U11 TIOC0D/PTE[12] Timer input output 0D/Port E
Y12 TIOC0C/PTE[13] Timer input output 0C/Port E
V11 TIOC0B/PTE[14] Timer input output 0B/Port E
W11 TIOC0A/PTE[15] Timer input output 0A/Port E
U12 VssQ Ground for I/O circuits (0V)
Y13 TCLKD/PTF[8] Timer Clock Input D/Port F
V12 VccQ Power supply for I/O circuits (3.3V)
W12 TCLKC/PTF[9] Timer Clock Input C/Port F
U13 TCLKB/PTF[10] Timer Clock Input B/Port F
Y14 TCLKA/PTF[11] Timer Clock Input A/Port F
V13
POE0/PTF[12]
Port output enable input 0/Port F
W13
POE1/PTF[13]
Port output enable input 1/Port F
U14
POE2/PTF[14]
Port output enable input 2/Port F
Y15
POE3/PTF[15]
Port output enable input 3/Port F
V14 PTF[0] Port F
Y16 PTF[1] Port F
U15 PTF[2] Port F
W14 PTF[3] Port F
V15 PTF[4] Port F
Y17 PTF[5] Port F
U16 Vcc Power supply (1.8V)
W15 PTF[6] Port F
U17 Vss Ground (0V)
