Section 19 Serial Communication Interface with FIFO (SCIF)

Rev. 4.00 Sep. 14, 2005 Page 688 of 982

REJ09B0023-0400

19.2 Pin

Configuration

The SCIF has the serial pins summarized in table 19.1.

Table 19.1 SCIF Pins

Channel Pin

Name

Abbreviation I/O Function

Serial clock pin

SCK0

I/O

Clock I/O

Receive data pin

RxD0

Input

Receive data input

Transmit data pin

TxD0

Output Transmit

data

output

Request to send pin

RTS0

I/O

Request to send

0

Clear to send pin

CTS0

I/O

Clear to send

Serial clock pin

SCK1

I/O

Clock I/O

Receive data pin

RxD1

Input

Receive data input

Transmit data pin

TxD1

Output Transmit

data

output

Request to send pin

RTS1

I/O

Request to send

1

Clear to send pin

CTS1

I/O

Clear to send

Serial clock pin

SCK2

I/O

Clock I/O

Receive data pin

RxD2

Input

Receive data input

Transmit data pin

TxD2

Output Transmit

data

output

Request to send pin

RTS2

I/O

Request to send

2

Clear to send pin

CTS2

I/O

Clear to send
