Renesas SH7641 User Manual
Page 511
Section 15 User Debugging Interface (H-UDI)
Rev. 4.00 Sep. 14, 2005 Page 461 of 982
REJ09B0023-0400
Bit Pin
Name
I/O
Bit Pin
Name
I/O
360
IRQ7/PTJ7 Control
328
TCLKD/PTF8 IN
359 SCK0/PTH0
Control 327 TCLKC/PTF9
IN
358
CTS0/PTH1 IN
326
TCLKB/PTF10 IN
357 TxD0/PTH2
IN
325 TCLKA/PTF11
IN
356 RxD0/PTH3
IN
324
POE0/PTF12 IN
355
RTS0/PTH4 IN
323
POE1/PTF13 IN
354 SCK1/PTH5
IN
322
POE2/PTF14 IN
353
CTS1/PTH6 IN
321
POE3/PTF15 IN
352 TxD1/PTH7
IN
320 PTF0
IN
351 RxD1/PTH8
IN
319 PTF1
IN
350
RTS1/PTH9 IN
318
PTF2
IN
349 SCK2/PTH10
IN
317 PTF3
IN
348
CTS2/PTH11 IN
316
PTF4
IN
347 TxD2/PTH12
IN
315 PTF5
IN
346 RxD2/PTH13
IN
314 PTF6
IN
345
RTS2/PTH14 IN
313
PTF7
IN
344 TIOC4D/PTE0
IN
312 PTG8
IN
343 TIOC4C/PTE1
IN
311 PTG9/SCL
IN
342 TIOC4B/PTE2
IN
310 PTG10/SDA
IN
341 TIOC4A/PTE3
IN
309 PTG11
IN
340 TIOC3D/PTE4
IN
308 PTG12
IN
339 TIOC3B/PTE6
IN
307 PTG13
IN
338 TIOC3C/PTE5
IN
306
CTS0/PTH1 OUT
337 TIOC3A/PTE7
IN
305 TxD0/PTH2
OUT
336 TIOC2B/PTE8
IN
304 RxD0/PTH3
OUT
335 TIOC2A/PTE9
IN
303
RTS0/PTH4 OUT
334 TIOC1B/PTE10
IN
302 SCK1/PTH5
OUT
333 TIOC1A/PTE11
IN
301
CTS1/PTH6 OUT
332 TIOC0D/PTE12
IN
300 TxD1/PTH7
OUT
331 TIOC0C/PTE13
IN
299 RxD1/PTH8
OUT
330 TIOC0B/PTE14
IN
298
RTS1/PTH9 OUT
329 TIOC0A/PTE15
IN
297 SCK2/PTH10
OUT
