Section 24 List of Registers
Rev. 4.00 Sep. 14, 2005 Page 874 of 982
REJ09B0023-0400
Register Name Abbreviation Bit No. Address Module Access States
USB interrupt enable register 1 USBIER1 8 H'A448 000D USB 8
USBEP1 receive data size register USBEPSZ1 8 H'A448 000F 8
USB interrupt select register 1 USBISR1 8 H'A448 0010 8
USB DMA transfer setting register USBDMAR 8 H'A448 0011 8
USBEP3 data register USBEPDR3 8 H'A448 0012 8
USBEP1 data register USBEPDR1 8 H'A448 0014 8/32
USBEP2 data register USBEPDR2 8 H'A448 0018 8/32
USB transceiver control register USBXVERCR 8 H'A448 001C 8
USB interrupt flag register 2 USBIFR2 8 H'A448 001D 8
USB interrupt enable register 2 USBIER2 8 H'A448 001E 8
USB bus power control register USBCTRL 8 H'A448 001F 8
— — — — — —
A/D0 data register A ADDRA0 16 H'A44E 0000 ADC 16
A/D0 data register B ADDRB0 16 H'A44E 0002 16
A/D0 data register C ADDRC0 16 H'A44E 0004 16
A/D0 data register D ADDRD0 16 H'A44E 0006 16
A/D1 data register A ADDRA1 16 H'A44E 0008 16
A/D1 data register B ADDRB1 16 H'A44E 000A 16
A/D1 data register C ADDRC1 16 H'A44E 000C 16
A/D1 data register D ADDRD1 16 H'A44E 000E 16
A/D0 control/status register ADCSR0 16 H'A44E 0010 16
A/D1 control/status register ADCSR1 16 H'A44E 0012 16
A/D0 A/D1 control register ADCR 16 H'A44E 0014 16
— — — — — —
Port A control register PACR 32 H'A443 0000 PFC 8/16/32
Port B control register PBCR 32 H'A443 0004 8/16/32
Port C control register PCCR 32 H'A443 0008 8/16/32
Port D control register PDCR 32 H'A443 000C 8/16/32
Port E control register PECR 32 H'A443 0010 8/16/32
Port F control register PFCR 32 H'A443 0014 8/16/32
Port G control register PGCR 32 H'A443 0018 8/16/32
Port H control register PHCR 32 H'A443 001C 8/16/32
