Section 25 Electrical Characteristics
Rev. 4.00 Sep. 14, 2005 Page 907 of 982
REJ09B0023-0400
Section 25 Electrical Characteristics
The specifications shown in this section are preliminary. After the characteristics have been
evaluated, the specifications may be changed without notice.
25.1 Absolute Maximum Ratings
Table 25.1 lists the absolute maximum ratings.
Table 25.1 Absolute Maximum Ratings
Item Symbol Value Unit
Power supply voltage (I/O) V
CC
Q
−0.3 to 3.8
V
Power supply voltage (Internal) V
CC
V
CC
(PLL1)
V
CC
(PLL2)
−0.3 to 2.1 V
Input voltage (other than ports G7 to G0) V
in
−0.3 to V
CC
Q
+0.3 V
Input voltage (ports G7 to G0) V
in
−0.3 to AV
CC
(A/D) +0.3 V
Analog power supply voltage (A/D) AV
CC
(A/D)
−0.3 to 3.8
V
Analog input voltage (A/D) V
AN
−0.3 to AV
CC
(A/D) +0.3 V
Operating temperature T
opr
−40 to +85 °C
Storage temperature T
stg
−55 to +125 °C
Caution: Permanent damage to the LSI may result if absolute maximum ratings are exceeded.
