Section 16 I

2

C Bus Interface 2 (IIC2)

Rev. 4.00 Sep. 14, 2005 Page 480 of 982

REJ09B0023-0400

Bit Bit

Name

Initial
Value R/W

Description

4

SDAOP

1

R/W

SDAO Write Protect

This bit controls change of output level of the SDA pin
by modifying the SDAO bit. To change the output level,
clear SDAO and SDAOP to 0 or set SDAO to 1 and
clear SDAOP to 0. This bit is always read as 1.

3

SCLO

1

R

This bit monitors SCL output level. When SCLO is 1,
SCL pin outputs high. When SCLO is 0, SCL pin
outputs low.

2

 1

 Reserved

This bit is always read as 1, and cannot be modified.

1

IICRST

0

R/W

IIC Control Part Reset

This bit resets the control part except for I

2

C registers. If

this bit is set to 1 when hang-up occurs because of
communication failure during I

2

C operation, I

2

C control

part can be reset without setting ports and initializing
registers.

0

 1

 Reserved

This bit is always read as 1, and cannot be modified.

16.3.3 I

2

C Bus Mode Register (ICMR)

ICMR is an 8-bit readable/writable register that selects whether the MSB or LSB is transferred
first, performs master mode wait control, and selects the transfer bit count.

ICMR is initialized to H'38 by a power-on reset.

Bit Bit

Name

Initial
Value R/W

Description

7 MLS 0 R/W

MSB-First/LSB-First

Select

0: MSB-first

1: LSB-first

Set this bit to 0 when the I

2

C bus format is used.

6

 0

 Reserved

The write value should always be 0.
