Section 2 CPU
Rev. 4.00 Sep. 14, 2005 Page 46 of 982
REJ09B0023-0400
Table 2.7
T Bit
This LSI's CPU
Description
Example of Other CPU
CMP/GE R1,R0
BT TRGET0
BF TRGET1
If R0
≥ R1, the T bit is set.
A branch is made to TRGET0
if R0
≥ R1, or to TRGET1 if R0 < R1.
CMP.W R1,R0
BGE TRGET0
BLT TRGET1
ADD #–1,R0
CMP/EQ
#0,R0
BT TRGET
The T bit is not set by ADD.
If R0 = 0, the T bit is set.
A branch is made if R0 = 0.
SUB.W #1,R0
BEQ
TRGET
Immediate Data: Byte immediate data is placed inside the instruction code. Word and longword
immediate data is not placed inside the instruction code, but in a table in memory. The table in
memory is referenced with an immediate data transfer instruction (MOV) using PC-relative
addressing mode with displacement.
Table 2.8
Immediate Data Referencing
Type
This LSI's CPU
Example of Other CPU
8-bit immediate
MOV
#H'12,R0 MOV.B
#H'12,R0
16-bit immediate
MOV.W
@(disp,PC),R0
........
.DATA.W H'1234
MOV.W #H'1234,R0
32-bit immediate
MOV.L
@(disp,PC),R0
........
.DATA.L H'12345678
MOV.L #H'12345678,R0
Note: Immediate data is referenced by @(disp,PC).
Absolute Addresses: When data is referenced by an absolute address, the absolute address value
is placed in a table in memory beforehand. Using the method whereby immediate data is loaded
when an instruction is executed, this value is transferred to a register and the data is referenced
using register indirect addressing mode.
