Section 16 I 2 C Bus Interface 2 (IIC2)
Rev. 4.00 Sep. 14, 2005 Page 476 of 982
REJ09B0023-0400
16.3 Register Descriptions
The I 2 C bus interface 2 has the following registers:
• I 2 C bus control register 1 (ICCR1)
• I 2 C bus control register 2 (ICCR2)
• I 2 C bus mode register (ICMR)
• I 2 C bus interrupt enable register (ICIER)
• I 2 C bus status register (ICSR)
• I 2 C bus slave address register (SAR)
• I 2 C bus transmit data register (ICDRT)
• I 2 C bus receive data register (ICDRR)
• I 2 C bus shift register (ICDRS)
• NF2CYC register (NF2CYC)
16.3.1 I 2 C Bus Control Register 1 (ICCR1)
ICCR1 is an 8-bit readable/writable register that enables or disables the I 2 C bus interface 2,
controls transmission or reception, and selects master or slave mode, transmission or reception,
and transfer clock frequency in master mode.
ICCR1 is initialized to H'00 by a power-on reset.
Bit Bit Name
Initial
Value R/W Description
7 ICE 0 R/W I 2 C Bus Interface Enable
0: This module is halted. (SCL and SDA pins are set to
port function.)
1: This bit is enabled for transfer operations. (SCL and
SDA pins are bus drive state.)
6 RCVD 0 R/W Reception Disable
This bit enables or disables the next operation when
TRS is 0 and ICDRR is read.
0: Enables next reception
1: Disables next reception
