Section 2 CPU
Rev. 4.00 Sep. 14, 2005 Page 47 of 982
REJ09B0023-0400
Table 2.9 Absolute Address Referencing
Type This LSI's CPU Example of Other CPU
Absolute address MOV.L @(disp,PC),R1
MOV.B @R1,R0
........
.DATA.L H'12345678
MOV.B @H'12345678,R0
16-Bit/32-Bit Displacement: When data is referenced with a 16- or 32-bit displacement, the
displacement value is placed in a table in memory beforehand. Using the method whereby
immediate data is loaded when an instruction is executed, this value is transferred to a register and
the data is referenced using indexed register indirect addressing mode.
Table 2.10 Displacement Referencing
Type This LSI's CPU Example of Other CPU
16-bit displacement MOV.W @(disp,PC),R0
MOV.W @(R0,R1),R2
........
.DATA.W H'1234
MOV.W @(H'1234,R1),R2
