Section 25 Electrical Characteristics
Rev. 4.00 Sep. 14, 2005 Page 910 of 982
REJ09B0023-0400
25.2 DC Characteristics
Tables 25.3 and 25.4 list DC characteristics.
Table 25.3 DC Characteristics (1) [Common Items]
Conditions: Ta
= −40°C to +85°C
Item Symbol Min. Typ. Max. Unit Test Conditions
Current
consumption*
1
Normal operation I
CC
* 2 — 300 400 mA V
CC
= 1.8 V
I φ = 100 MHz
P φ = 33 MHz
I
CC
Q* 3 — 10 20 mA V
CC
Q = 3.3 V
B φ = 50 MHz
Standby mode I
stby
* 2 — 200 1000 µA
I
stby
Q* 3 — 5 20 µA
Sleep mode I
sleep
* 2 — 50 110 mA
Ta = 25 °C
V
CC
Q = 3.3 V
V
CC
= 1.8 V
B φ = 50 MHz
P φ = 33 MHz
Input leakage
current All input pins |I
in
| — — 1.0 µA V
in
=
0.5 to V
CC
Q – 0.5 V
Three-state
leakage
current All input/output pins,
all output pins
(except for pins with
weak keeper)
(off state) |I
STI
| — — 1.0 µA Vin =
0.5 to V
CC
Q – 0.5 V
Input
capacitance All pins C
in
— — 20 pF
Analog power
supply voltage
(A/D) AV
CC
(AD) 3.0 3.3 3.6 V
During A/D
conversion — 2 5 mA Analog power
supply current
(A/D)
Idle
AI
CC
(AD)
— 600 1000 µA
Caution: When the A/D converter is not in use, the AV
CC
and AV
SS
pins should not be open.
Note: 1. Current consumption values are when all output pins are unloaded.
2. I
CC
I
sleep
and I
stby
, respectively, represents the total currents consumed in each Vcc, V
CC
(PLL1) and Vcc (PLL2)
3. I
CC
Q and I
stby
Q, respectively, represents the total currents consumed in each V
CC
Q and
AV
CC
.
