Section 24 List of Registers
Rev. 4.00 Sep. 14, 2005 Page 872 of 982
REJ09B0023-0400
Register Name Abbreviation Bit No. Address Module Access States
Timer control register_1 TCR_1 8 H'A449 0080 MTU 8/16
Timer mode register_1 TMDR_1 8 H'A449 0081 8/16
Timer I/O control register _1 TIOR_1 8 H'A449 0082 8
Timer interrupt enable register_1 TIER_1 8 H'A449 0084 8/16/32
Timer status register_1 TSR_1 8 H'A449 0085 8/16/32
Timer counter_1 TCNT_1 16 H'A449 0086 8/16/32
Timer general register A_1 TGRA_1 16 H'A449 0088 16/32
Timer general register B_1 TGRB_1 16 H'A449 008A 16/32
Timer control register_2 TCR_2 8 H'A449 00A0 8/16
Timer mode register_2 TMDR_2 8 H'A449 00A1 8/16
Timer I/O control register_2 TIOR_2 8 H'A449 00A2 8
Timer interrupt enable register_2 TIER_2 8 H'A449 00A4 8/16/32
Timer status register_2 TSR_2 8 H'A449 00A5 8/16/32
Timer counter_2 TCNT_2 16 H'A449 00A6 16/32
Timer general register A_2 TGRA_2 16 H'A449 00A8 16/32
Timer general register B_2 TGRB_2 16 H'A449 00AA 16/32
Input level control/status register 1 ICSR1 16 H'A44C 0000 8/16/32
Output level control/status register OCSR 16 H'A44C 0002 8/16/32
— — — — — —
Serial mode register_0 SCSMR_0 16 H'A440 0000 SCIF 16
Bit rate register_0 SCBRR_0 8 H'A440 0004 8
Serial control register_0 SCSCR_0 16 H'A440 0008 16
Transmit FIFO data register_0 SCFTDR_0 8 H'A440 000C 8
Serial status register_0 SCFSR_0 16 H'A440 0010 16
Receive FIFO data register_0 SCFRDR_0 8 H'A440 0014 8
FIFO control register_0 SCFCR_0 16 H'A440 0018 16
FIFO data count register_0 SCFDR_0 16 H'A440 001C 16
Serial port register_0 SCSPTR_0 16 H'A440 0020 16
Line status register_0 SCLSR_0 16 H'A440 0024 16
Serial mode register_1 SCSMR_1 16 H'A441 0000 16
