Section 1 Overview
Rev. 4.00 Sep. 14, 2005 Page 21 of 982
REJ09B0023-0400
Classification Symbol I/O
Name
Function
DREQ0,
DREQ1
I DMA-transfer
request
Input pin for external requests for
DMA transfer.
DACK0,
DACK1
O DMA-transfer
request receive
Output pin for request receive, in
response to external requests for
DMA transfer.
Direct memory
access controller
(DMAC)
TEND0
O DMA-transfer
end
output
Output pin for DMA transfer end
signal
TCK
I
Test clock
Test-clock input pin.
TMS
I
Test mode select Inputs the test-mode select signal.
TDI
I
Test data input
Serial input pin for instructions and
data.
TDO
O
Test data
output
Serial output pin for instructions and
data.
User debugging
interface
(H-UDI)
TRST
I
Test reset
Initialization-signal input pin.
AUDATA3 to
AUDATA0
O
AUD data
Data output pins in AUD-trace mode.
AUDCK
O
AUD clock
Sync-clock output pin in AUD-trace
mode.
Advanced user
debugger
(AUD)
AUDSYNC
O
AUD sync
signal
Data start-position acknowledge-
signal output pin in AIUD-trace
mode.
ASEBRKAK O Break
mode
acknowledge
Indicates that the E10A emulator has
entered its break mode.
For the connection with the E10A,
see the SH7641 E10A Emulator
User's Manual (tentative title).
E10A interface
ASEMD0
I
ASE mode
Sets the ASE mode.
SCL
I/O
Serial clock pin
Serial clock input/output pin
I
2
C bus interface 2
SDA
I/O
Serial data pin
Serial data input/output pin
