Section 13 Direct Memory Access Controller (DMAC)
Rev. 4.00 Sep. 14, 2005 Page 427 of 982
REJ09B0023-0400
Table 13.5 Selecting External Request Detection with Dl, DS Bits
CHCR
DL DS Detection of External Request
0 Low level detection 0
1 Falling edge detection
0 High level detection 1
1 Rising edge detection
When
DREQ is accepted, the DREQ pin becomes request accept disabled state (non-sensitive
period). After issuing acknowledge signal
DACK for the accepted DREQ, the DREQ pin again
becomes request accept enabled state.
When
DREQ is used by level detection, there are following two cases by the timing to detect the
next
DREQ after outputting DACK.
Overrun0: Transfer is aborted after the same number of transfer has been performed as requests.
Overrun1: Transfer is aborted after transfers have been performed for (the number of requests
plus 1) times.
The DO bit in CHCR selects this overrun 0 or overrun 1.
Table 13.6 Selecting External Request Detection with DO Bit
CHCR_0 or CHCR_1
DO External Request
0 Overrun 0
1 Overrun 1
