Examine the Basic Workflow
Example Trend Monitoring Test: Basic Workflow
Basic Workflow Description
Description
Item
Ramp activity.
1
Parallel Paths activity (expanded).
2
Sweep activity in the Command path.
3
Trend Monitoring activity in Monitor Trend path.
4
While Loop activity (collapsed) in the Trip Action path.
5
Run Report activity.
6
