MTS Multipurpose Elite User Manual
Page 174
Description
Item
Number
Variable Actions Menu
Selects which columns you want to show in the variables table.
Column Chooser
2
Column Chooser
Filters by your selected filter criteria and sorts in ascending or descending
order. If a filter for a column is currently active, the filter icon appears
blue.
Filter and Sort
Icons for Columns
3
Filter
Shows the properties for the variable currently selected in the variables
table.
Selected variable
4
Shows the properties for the currently selected variable.
Properties
5
For More Information
Concept
(p. 177)
174 | MTS TestSuite
Working with Variables
