MTS Bend Fixture-300 kN User Manual
Bend fixture, 300 kn, Mts fundamental, Accessories
Copyright information
© 2010 MTS Systems Corporation. All rights reserved.
Trademark information
MTS is a registered trademark and MTS Fundamental is a
trademark of MTS Systems Corporation within the United
States. These trademarks may be protected in other countries.
Contact information
MTS Systems Corporation
ISO 9001 Certified QMS
Specifications
Model
F-JW305A1.01 -
01
-02
-03
-04
-05
-06
-07 -08 -09
-10
-11
-12
Maximum Load (kN)
300
Width (mm)
570
Depth (mm)
230
Support Weight (kg)
60
Support Height (mm)
150
Maximum Roller Center
Distance (mm)
350
Roller Diameter (mm)
Φ36
Former Diameter (mm)
Φ18 Φ24 Φ30
Φ36 Φ42 Φ48 Φ54 Φ60 Φ66
Φ75 Φ84 Φ96
Former Series
A
B1
B1
B2
B2
B2
B2
B2
B3
B3 B3 B3
Former Support Range
16-22 22-35
36-65
66-120
Roller Length (mm)
125
Temperature Range (°C)
0 to +50
Saline Tolerant
No
Immersion Proof
No
Bend Fixture, 300 kN
MTS Fundamental
™
Accessories
100-230-741
