MTS Multipurpose Elite User Manual
Page 542
Variables Selection Window
Variables Selection Properties
Description
Item
This panel shows the Category and Display Name of all variables that
are available for use in the current context. In some contexts, for example,
Available
Variables
only string variables are valid. In other contexts, array variables are not
valid.
This panel shows the Category and Display Name of all variables that
are selected for use. To reorder selected variables, select the variable
and click the up or down arrows.
Selected
Variables
Adds a single variable that you have selected on the Available Variables
panel to the Selected Variables panel.
Right Arrow
Adds all the variables that currently appear on the Available Variables
panel to the Selected Variables panel.
Double Right
Arrow
Removes a single variable that you have selected on the Selected
Variables panel.
Left Arrow
Removes all the variables that currently appear on the Selected Variables
panel.
Double Left Arrow
542 | MTS TestSuite
