Setting Continuous Span and Setpoint Values
Follow these steps to add a Span and Setpoint activity with the Continuous Monitor option. Typically, this
is added to a test workflow in a parallel path in conjunction with another command activity.
1. Add a Set Span and Setpoint activity to the desired location in the test workflow.
2. From the Monitor list, select the Continuous option.
3. Select a Channel and a Control Mode.
4. Select or define a variable for the Span value and unit.
5. Select or define a variable for the Setpoint value and unit.
6. If applicable, select the Allow activity to execute when the test is stopped check box.
For More Information
Concept
Set Span and Setpoint Activity Overview
(p. 424)
Reference
(p. 425)
Set Span and Setpoint Activity Properties
(p. 426)
Example: Setting Span and Setpoint
(p. 430)
Example: Maintain Command Test Design
(p. 431)
Maintaining Command to Prevent Movement
Use the Set Span and Setpoint activity with a Maintain command in conjunction with other multiple
instances of the activity. The Set Span and Setpoint activity with a Maintain command is not intended for
use as a singular activity within a test design.
Important:
Placing the Set Span and Setpoint activity with a Maintain command in parallel with another
Commands activity using the same channel results in a runtime error. Place the activity as a serial
activity within the test workflow.
1. Add a Set Span and Setpoint activity to the test workflow.
2. Select the Maintain command to prevent movement check box.
3. Select a Channel and a Control Mode.
4. Define the Span and Setpoint values as appropriate to accomplish the objective of your test design.
5. If applicable, select the Allow activity to execute when the test is stopped check box.
